IP65 Handheld RFID Reader PDA
IP65 Handheld RFID Reader PDA
IP65 Handheld RFID Reader PDA
IP65 Handheld RFID Reader PDA
IP65 Handheld RFID Reader PDA

IP65 Handheld RFID Nyeem Ntawv PDA

Txheej txheem cej luam Rugged Industrial PDA Scanner Android8.1 S917V2 rugged handheld pdas android8.1 barcode scanner SENTER S917V2 5.5 nti Android handheld PDA davhlau ya nyob twg -4G RAM, 64G ROM octa core 1.8GHZ CPU -IP67 tiv thaiv qib chaw nres tsheb, dpiocking barcode barcode Ntsiab nta Advanced system...

Xa kev nug

Khoom Taw qhia

Yog tias koj xav tau ip65 handheld rfid nyeem ntawv pda los pab nrog koj lub lag luam, thov kom dawb mus yuav nrog peb lub Hoobkas. Raws li ib qho ntawm cov ua lag luam nyob hauv Suav teb, peb yuav muab koj cov nqi qis thiab cov kev pabcuam tsis sib xws.

Txheej txheem cej luam

Rugged Industrial PDA Scanner Hauv 8.1

S917V2 rugged handheld pdas android8.1 barcode scanner SENTER S917V2 5.5 nti Android handheld PDA davhlau ya nyob twg -4G RAM, 64G ROM octa core 1.8GHZ CPU -IP67 tiv thaiv qib -2D barcode scanner, rab phom tuav, chaw nres tsheb
Cov yam ntxwv tseem ceeb
Advanced system
Android 8.1 operating system, CPU Qualcomm SDM450, 8core 1.8GHz, RAM 4G ROM 64G, Micro SD 128GPom pom hauv qab lub teeb muaj zog
5.5 nti LCD npo, 1920 * 1080IPS capacitive kov npo nrog 500 nits ci
Ua haujlwm muaj zog
Muaj nuj nqi,1D / 2D barcode scanning, LF / HF / UHF RFID nyeem ntawv, cim ntiv tes
Ntau hom kev sib txuas lus
3G / 4G, WIFI, BT thiab ntau hom kev sib txuas lus wireless
Txhawb jcaket extension
Txaus siab rau cov ntawv thov kev cai los ntawm cov neeg siv khoom
Kev tiv thaiv kev lag luam
IP65 qib peb tiv thaiv, poob tsis kam ntawm 1.2m
Roj teeb
3.8V, 5000mAh, txhawb nqa ceev ceev
Ntawv pov thawj
CCC/CE/ROSH/FCC/IP67/MIL-STD-810G
Dimension
173 * 87 * 16.4mm, 350g
General Specifications
General Specification

Zaub Screen
5.5 nti LCD npo, 1920 * 1080IPS npo, 500 nits brightness txheem capacitive kov npo

Kev Ua Haujlwm
Hauv 8.1

CPU
Qualcomm SDM450 8core, 1.8GHz

GPU
Qualcomm Adreno 5.9 GPU

RAM& ROM
RAM 4G ROM 64G, Micro SD siab tshaj 128G

USB chaw nres nkoj
Hom-C chaw nres nkoj; Txhawb rau txuas U-disk / Nas / Keyboard / OTG kab

OTG
Los ntawm OTG tuaj yeem ntsib 100M network chaw nres nkoj, teeb tsa lub network, PPPoE dial-up, web browsing.Support OTG txuas RS232 serial chaw nres nkoj / RJ45 chaw nres nkoj / 485 serial chaw nres nkoj)

Sab nraud chaw nres nkoj
Charge port, headphone port

Qib tiv thaiv

Industrial Protection Qib
IP65

Muab Qib
Poob tsis kam los ntawm 1.2m

Kev sib txuas lus wireless

BT
Txhawb nqa 4.1

GPS
Default GPS: GPS 10m

WIFI
Txhawb IEEE 802.11a/b/g/n/ac, 2.4G thiab 5G dual band

2G / 3G / 4G LTE
CDMA 1X/EVDO BC0GSM 850/900/1800/1900
WCDMA B1/B2/B5/B8
TD-SCDMA B34/B39
FDD-LTE B1/B3/B5/B7
TD-LTE B38/B39/B40/B41

Lub cev Parameters

Lub koob yees duab
5MP pem hauv ntej lub koob yees duab, 13MP rear koob yees duab nrog tsis siv neeg tsom xam thiab teeb pom kev zoo muaj nuj nqi

Keyboard
Khawm: Ib lub khawm scan ntawm sab (bar code thiab UHF tuaj yeem siv ua ke), ib lub zog khawm, ntim ntxiv thiab khawm rho tawm.Lub 3 lub cev muaj nuj nqi yuam sij (Rov qab ntawv qhia HOME)

Headset
3.5mm audio interface

Mic thiab Loudspeaker
Txhawb nqa

LED qhov taw qhia teeb
Kev them nyiaj yug (ib txwm flicker, Hu ceev flicker, hu tsis tau, qhia nqi)

Lub teeb muaj nuj nqi
Kev them nyiaj yug, tuaj yeem siv rau kev teeb pom kev kub ceev

Lub ntiajteb txawj nqus Sensor
Txhawb nqa

Compass
Txhawb nqa

Acceleration sensor
Txhawb nqa

Gyroscope sensor
Txhawb nqa

Lub teeb thiab nrug Sensor
Txhawb nqa

FM
Txhawb nqa

Lithium roj teeb
3.8V, 5000mAh, txhawb nqa ceev ceev (QC3.0)

Dimension
173 * 87 * 16.4 hli

Qhov hnyav
650g

Cov yam ntxwv ntawm ib puag ncig

Ua haujlwm kub
-10°C~+50°C

Cia Kub
-40°C~+60°C

Cov av noo
5% -95% txheeb ze humidity; tsis condensation

Xaiv muaj nuj nqi

Barcode Scanning
1D Laser Scanner Index (Internal):
Honeywell N4313
Scanning ceev: 104 zaug / thib ob+ 12 zaug / thib ob (ob txoj kev scanning)
Scanning ceev: 2.5cm-114.3cm
Scanning ceev: 47 ± 3 ° (default) 35 ± 3 ° (txo code)
2D Barcode Scanner Index (Internal):
Kev xaiv modules: Newlands EM3296, los yog Honeywell N3680, los yog HoneywellN6603
Kev paub muaj peev xwm: 1D, 2D, OCR
Lub kaum ntse ntse scan: tig 360 °, incline ± 50 °, poob ± 50 °
Field of View: Kab rov tav 36 °, ntsug 23 °
Qhov tob: 4cm-23.5cm
Environmental luminance: 0 ~ 100,000 LUX

RFID
NFC RFID (Internal)
Txhawb 13.56MHz, ISO14443A, B, ISO15693 raws tu qauv, Txhawb Mifare daim npav, nyeem ntawv nrug 0-3cm

LF RFID (hauv lub tsho):
134.2KHz LF RFID txhawb ISO11784/5 raws tu qauv, txhawb kev nyeem EM, TEMID, TK phaib thiab tshaj IC daim npav (FDX / HDX)
LF RFID (hauv lub tsho):
125KHz LF RFID, txhawb nqa daim npav ID

UHF RFID (hauv lub tsho):
Ua hauj lwm zaus: 902-928MHz los yog 865-868MHz (M2600, lmpinjR2000 nti)
Nyeem nrug: tsis pub tshaj 6m

rab phom tuav
Nrog cov roj teeb sab hauv thiab khawm scan (4800mAh roj teeb sab hauv)

Duab
