ST805C ' meter ' kho qhov muag zog Pon, SC/APC Adapter, SC/PC Adapter, Handheld PON zog ' meter ' 1310/1490/1550nm, USB chaw nres nkoj
Ⅰ. Saib ib muag
' Meter ' fais ST805C PON no yeej tsim rau cov PON network siv thiab cov txij nkawm. Itand #39; s ib tug pab tau kawm ntawv xeem uas tus engineers thiab nkawm tswv ntawm PON network ntawm FTTX.
Nws yuav ua tau in-service no los soj ntsuam txog tag nrho cov PON Pib ntsais koj teeb (1310/1490/1550nm) rau tej chaw ntawm lub network. Tsom xam pass/xeem yog conveniently pom tau hais los ntawm usersand #39; adjustable Harbor ntawm txhua lub wavelength.
Adopting 32 xaus CPU uas tsis tshua muaj zog noj, ST805C yuav ntau haib thiab sai heev. Nhav ntsuas seb tshuav nqi rau kev zov me nyuam tus phooj ywg interface.
Ⅱ. nrhav nta
Sim 3 wavelengthsand #39; zog ntawm cev PON synchronously: 1490nm, 1550nm, 1310nm
Haum rau txhua PON network (APON, BPON, GPON, EPON)
Neeg txhais Harbor poob lawm
Muab lus 3 pawg Harbor qhov tseem ceeb; tsom xam thiab tso saib raws li txoj cai tshaj/xeem
Tus kwv tij tus nqi (plawg poob)
Txuag thiab upload cov ntaub ntawv rau lub computer
Muab tus nqi Harbor, upload cov ntaub ntawv, thiab calibrate wavelength los ntawm kev tswj software
32 xaus CPU, yooj yim rau koj khiav lag luam, yooj yim thiab kab ntsab
Nws pib fais fab tua, nws pib backlight tua voltage luv fais fab tua
Xibtes nqi npaum luaj li cas tsim los rau cov teb thiab kuaj (lab)
Yooj yim rau-siv cov interface uas muaj zaub ntau heev rau visibility yooj yim
Ⅲ. Loj zog
3 wavelengthsand #39; zog ntawm cev PON synchronously: 1490nm, 1550nm, 1310nm
kuaj cov tawg ntho hom teeb liab ntawm 1310nm
Harbor nqi sijhawm muaj nuj nqi
Cov ntaub ntawv cia muaj nuj nqi
Nws pib backlight tua muaj nuj nqi
Zaub rau voltage cov roj teeb
Fais fab tua yuav thaum nws tseem nyob rau koj voltage uas tsis muaj
Moos real-time zaub
IV. Specifications
Wavelength | ||||
Txheem wavelengths | 1310 (ntws los) | 1490 (downstream) | 1550 (downstream) | |
Tshaj zone(nm) | 1260~1360 | 1470~1505 | 1535~1570 | |
Range(dBm) | -40~+10 | -45~+10 | -45~+23 | |
Kev rho tawm @1310nm(dB) | andgt; 40 | andgt; 40 | ||
Kev rho tawm @1490nm(dB) | andgt; 40 | andgt; 40 | ||
Kev rho tawm @1550nm(dB) | andgt; 40 | andgt; 40 | ||
Neeg | ||||
Uncertainty(dB) | ±0.5 | |||
Polarization tub tsi (dB) | andlt; ±0.25 | |||
Linearity(dB) | ±0.1 | |||
Mus zoo Loss(dB) | andlt; 1.5 | |||
Daws teeb meem | 0.01dB | |||
Tsev | dBm / xW | |||
Specifications xwb | ||||
Naj npawb cia | khoom 99 | |||
Nws pib backlight rho tawm hauj lwm lub sij hawm | 30 30 feeb li ntawd tsis muaj lag luam | |||
Nws pib fais fab tua lub sij hawm | 10 feeb tsis muaj lag luam | |||
Roj teeb | 7.4V 1000mAH rechargeable Lithium roj teeb los roj teeb qhuav | |||
Nruam ua hauj lwm | 18 teev rau roj teeb Lithium; li 18 teev rau qhuav roj teeb ib yam nkaus thiab, tab sis nyias rau nyias roj teeb hom | |||
Kub ua hauj lwm | -10 ~ 60 ° C | |||
Kub cia | -25 ~ 70 ° C | |||
Dimension (hli) | 200*90*43 | |||
Ceeb thawj (g) | 330 li | |||
Saj zawg zog qhov zoo sib xws
VI. Ports
VII. Ordering Information
| Khoom | Lub npe | Kom muaj nuj nqis |
1 | ST805C PON zog | 1 |
2 | SC/SC Jumper hlau | 1 |
3 | Charger (rau roj teeb rechargeable) | 1 |
4 | USB Line | 1 |
5 | Tswj Software CD | 1 |
6 | Neeg siv lawm | 1 |
7 | BB-002Clean paj rwb lo | 1 pob |
Thov xaiv tus sub raws qauv hauv qab no:
ST805C | Connector | Roj teeb |
ST805C-A | SC/APC | AA roj teeb qhuav |
ST805C -B | SC/APC | Li-ion rechargeable roj teeb |
ST805C - C | SC/PC | AA roj teeb qhuav |
ST805C -D | SC/PC | Roj teeb lis-ionrechargeable |
