ST327 With Fiber Ranger Module
ST327 Telecom Test PDA With Fiber Ranger Module
ST327 Telecom Test PDA With Fiber Ranger Module

Handheld OTDR tester 5.6 nti xim screen

Kev Ua Tau Zoo Test5.6 nti xim TFT LCD zaub, kov lossis qhov tseem ceeb dual kev ua haujlwm Dynamic ntau: 35 / 33dB, qhov siab tshaj plaws rau 45dBLess dua li 0.8 metres ultra luv luv qhov teeb meem thaj chaw kuaj qhov muag fiber ntau jumper dawbLink optical nondestructive kuaj teeb liab pom tau muaj nuj nqi (Kev tiv thaiv zoo ntawm APD) Ntau Qhov Kev Ntsuas Kab Ntsig - Txheem Kho Txiaj Txheej Txheem Khoos MobtDRlaser sourceVFLOPM

Xa kev nug

Khoom Taw qhia

ST3200C series OTDR

5.6 nti xim kov lub vijtsam

khawm thiab kov lub sijhawm ua haujlwm

8 muaj nuj nqi modules

Max 45 dB dynamic ntau yam, tuaj yeem nkag mus rau qhov sib cais optical, txhawb PON network kuaj

20 teev ntev standby

Lub ntsiab Specification:

OTDR
Qauv	ST3200C-A	ST3200C-B-B	ST3200C-C -C	ST3200C-D	ST3200C-E	ST3200C -F	ST3200C -G	ST3200C-H	ST3200C-Kuv
Hom	SM							HLI	SM / HLI
Wavelength	1310nm / 1550nm				1310nm / 1490nm / 1550nm	1310nm / 1550nm / 1625nm	1310nm / 1490nm / 1550nm / 1625nm	850nm / 1300nm	850nm / 1300nm / 1310nm / 1550nm
Max Kev khwv Muaj Zog	35 / 33dB	38 / 36dB	42 / 40dB	45 / 43dB	37/35 / 35dB	37/35 / 35dB	37/35/35 / 35dB	28 / 26dB	28/26/35 / 33dB
Qhov Muag Tsis Pom Cheeb Tsam	1m	0.8m	0.8m	0.8m	0.8m	0.8m	0.8m	lm	lm
ATT qhov muag tsis pom thaj chaw	6m	6m	6m	6m	6m	6m	6m	6m	6m
Kuaj Ntau	500m / 1 km / 2km / 4km / 8km / 16km / 32km / 64km / 12 8km / 256km
Mem Tes Dav	3ns / 5ns / 10ns / 30ns / 50ns / 80ns / 160ns / 320ns / 500ns / 800ns / 1000ns / 3000ns / 5000ns / 8000ns / 10000ns / 20000ns
Xws li qhov tseeb	± (0.75m {{2}} Lub sijhawm luv qauv +0.005 % x Xeem nrug)
Poob raug	0.05dB / dB
Qauv ntsiab lus	16k〜256k
Qauv Kev daws teeb meem	0.05m~16m
Cia Siab Tias Yuav Raug	3dB
Ntaub Ntawv Hom	SOR Daim Ntawv Cov Qauv Ntaub Ntawv
Kev Tshawb Fawb	4-point txujci / 5-taw tes qauv
Laser Kev Ruaj Ntseg Theem	Chav Kawm II

Lwm cov ua haujlwm module:

Lwm tus
Tso saib	5.6 nti xim xim LCD thiab lub vijtsam kov
Khoom siv fais fab	AC / DC Adapter ： Cov Lus Tshaj Tawm ： 100V〜240V, 50 / 60Hz, 0.6A Tawm Tawm ： 12V-19V, 1.5A Li-Roj Teeb ： 7.4V, 5200mAh
Lub Sijhawm Ua Haujlwm Kub	-10°C 〜+50°C
Cia Khoom Kub	-40°C 〜+70°C
Tus Txheeb Ze Xaj	0 〜95%, Tsis Them Nqi
Nyhav	≤1.2kg
Qhov Coob	227mmx 160mmx70min
Cov Kev Ua Haujlwm Ntawm Tus Tswv Tsev ： PON OTDR / OPM / VFL / LS / Daim Ntawv Qhia Caij / Fibre Cov Kev Tshawb Nrhiav Thaum Fais Fab (Cov Ntsuas Cov Ntsuas Ntxiv) / Kev Ntsuas Tsis Zoo

Kho Siab Ntaus Nqi	3Hz (Ntaus.)
Cov ntaub ntawv cia	Kev cia sab hauv ： 100M (GG lt; 3000 nkhaus) storage Cia rau sab nraud ： 4G me ntsis
Khoom Txuas	FC / UPC (Sib Pauv Hloov SC 、 ST)
Cov ntaub ntawv sib cuam tshuam	USB 、 Mini-USB 、 10M / 100M Ethernet Chaw Nres Nkoj
OPM
Wavelength ntau	800nm ~ 1700nm
Khoom Txuas	Universal sib koom ua ke FC / SC / ST
Xeem Ntawv	-50dBm〜+26dBm
Tsis paub tseeb	±5%
Calibration Wavelength	850nm / 980nm / 1300nm / 1310nm / 1490mn / 1550nm / 1625mn / 1650nm
LS
Laser Hom	FP-LD
Wavelength	Raws li OTDR tso tawm nthwv cua
Rau Cov Zis	GG gt; -5dBm
Kev ruaj khov	CW, ± 0.5dB / 15min (Kev ntsuam xyuas tom qab 15 feeb ntawm kev ntsuas)
Khoom Txuas	FC / UPC (Sib Pauv Hloov SC 、 ST)
VFL
Wavelength	650nm ± 20nm
Tsim tawm hwj chim	GG gt; 2mW
Hom	CW / lHz / 2Hz
Khoom Txuas	FC / UPC (Interchangeable SC> ST)
Lub Txheej Txheem Tshaj Tawm Optical Loss Test hais txog saum toj no LS thiab OPM index.

Cov Ntawv Sau:

TSIS MUAJ.	Kev piav qhia	Qty	Cov lus ceeb toom
1	OTDR tester	1	Roj teeb nrog
2	AC / DC hloov khoom siv	1
3	U disk (suav nrog tsom software / Tus neeg siv phau ntawv	1
4	Kov cwj mem	1
5	Cov ntaub ntawv kab	1
6	SC adapter	1
7	OPM SC adapter	1
8	Kev ua haujlwm phau ntawv	1
9	Cov lus qhia phau ntawv	1
10	Cov ntaub ntawv ntsuas kev ua haujlwm	1
11	Daim npav Warranty	1
12	Cov paj rwb huv	10
13	Tawv pob qhov rooj	1
14	Lub hnab ev ntawv tshwj xeeb rau qhov ntsuas	1
