UHF HANDHELD NYEEM-TSO DEJ RAUG SAWV DAWS LOS POM ZOO
Android 9.0 system · UHF ultra ntev nyeem thiab sau ntawv
5.7-nti HD Durable Loj Zaub · Kev kub ceev Octa- tseem ceeb
Cov khoom lag luam | |
Kev ua tau zoo | |
Tub ntxhais Octa | |
CPU | Cortex-A53 Octa-core 64-ntsis 2.0GHz kev ua haujlwm siab |
RAM + ROM | 3GB+32GB Txheem Txhawb nqa mus txog 4GB+64GB |
Nthuav nco | Micro SD (TF) Txhawb nqa mus txog 128GB |
Txheej Txheem | Hauv 9.0 |
Cov ntaub ntawv kev sib txuas lus | |
WLAN | Band ob pawg 2.4GHz / 5GHz, Txhawb nqa IEEE 802 a / b / g / n / ac raws tu qauv |
WWAN | 2G ： GSM （850/900/1800 / 1900mhz） |
3G ： WCDMA （850/900/1900 / 2100mhz） | |
4G ： FDD: B1 / B3 / B4 / B7 / B8 / B12 / B20 | |
TDD: B38 / B39 / B40 / B41 | |
Bluetooth | Txhawb Bluetooth 2.1+EDR / 3.0+HS / 4.1+HS Kev hloov mus deb 5-10 meters |
GNSS | Txhawb Nqa Gps, Galileo, Glonass, Beidou |
Lub cev tsis dhau los | |
Qhov ntev | 159mm × 75mm × 124mm |
Nyhav | ＜500g (Nyob ntawm ntaus muaj nuj nqi configuration） |
Tso saib | 5.7 nti IPS xim zaub nrog daws teeb meem 720 * 1440 |
Qhov TP | Corning liab twm hawj iav, Txhawb kov ntau Txhawb cov hnab looj tes thiab txhais tes ntub |
Muaj peev xwm roj teeb | Roj teeb polymer ua kom rov ua dua tshiab (3.8V 5000MAh) tshem tau |
Lub sijhawm sawv ntsug> 350 teev | |
Lub sijhawm ua haujlwm> 12 teev | |
Them lub sijhawm 3-4H, Siv tus qauv fais fab adapter thiab cov ntaub ntawv cable | |
Kev nthuav dav Daim npav qhov | PSAM x 2, Nano daim npav x 1, Daim npav TF × 1 |
Kev sib txuas lus interface | Hom-C USB x 1, OTG |
Suab | Hais lus (mono), Microphone, Earpiece |
Lub ntaus pob | Lub zog khawm, ntim + / - khawm, Luam theej duab khawm × 2 Kov scan khawm × 1 |
Cov Ntsuas | Lub ntiajteb txawj nqus sensor, Lub teeb sensor, Daws daws sensor, Kev co lub cev muaj zog |
Cov ntaub ntawv sau | |
Tshawb Barcode (Yeem) | |
2D Imager scanner | Meb Vaj N3603 |
2D Symbologies | PDF417, Micro PDF417, GS1 Composite, Aztec Code, Cov Ntaub Ntawv Matrix, QR Code, Micro QR Code, Maxicode, Hanxin Code, thiab lwm yam. |
UHF | |
Cav | Cav CM2000-1, raws li Impinj Indy R2000 |
Zaus (CHN) | 920-925MHz |
Zaus (USA) | 902-928MHz |
Zaus (EHR) | 865-868 MHz （ETSI EN 302 208） |
Zaus (Lwm Yam) | Lwm cov qauv ntsuas ntau zaus (tuaj yeem kho tau) |
Raws tu qauv | EPC C1 GEN2 / ISO18000-6C / 6B |
Kav hlau txais xov | Kav hlau txais xov circularly polarized (4dBi) |
Lub Zog | 30dBm, txhawb +5dBm ~ +30dBm hloov kho |
Qhov deb | 0-13m |
Nyeem nrawm | GG gt; 200 cim ib pliag (sib ncawg sib luag) |
Nco tseg: * Daim npav nyeem ntawv qhov deb thiab qhov nyeem hauv pab pawg muaj feem cuam tshuam nrog qhov chaw ib puag ncig | |
Lub Koob Yees Duab | |
Tsheb cov koob yees duab | 13MP HD lub koob yees duab, Txhawb nws pib ua kom pom tseeb, Nyem, Los tiv thaiv co, Macro tua |
Pem hauv ntej lub koob yees duab | Lub koob yees duab 2MP xim |
NFC (yeem) | |
Zaus | 13.56MHz |
Raws tu qauv | Txhawb nqa ISO14443A / B, 15693 pom zoo |
Qhov deb | 2cm-5cm |
Cov hom lus / tswv yim | |
Cov lus qhia | Lus Askiv, Pinyin, Tsib tus cwj nrag, Ntaus ntawv sau cov lus, Txhawb cov ntaus cim muag |
Lus | Cov lus nyob rau hauv Suav tau yooj yim, Tsoos suav, Askiv, Korean, Japanese, Malaysian, thiab lwm yam. |
Neeg siv ib puag ncig | |
Kev khiav hauj lwm kub | -20℃ - 55℃ |
Cia kub | -40℃ - 70℃ |
Ib puag ncig cov av noo | 5% RH - 95% RH (tsis muaj hws) |
Tee specification | 6 sab Kev Pab txhawb nqa 1.2 metres tee thiab 30 zaug rau cov qhob hauv qhov khiav hauj lwm kub |
Dov xeem | 500 × 0.5m dov rau 6 sab |
Khoom Plig | |
Txuj Ci | Adapter, Cov ntaub ntawv cable, Kev tiv thaiv zaj duab xis, Cov lus qhia phau ntawv |
