LiDAR Visual Intelligent Monitoring
√ Lub luag haujlwm lub cuab yeej siv lub koob yees duab dual - qauv tsim qauv
√ Nruab nrog lub hnub qub- theem qis- lub koob yees duab teeb pom kev zoo
√ Point Cloud Real-time Collection, LiDAR (Light Detection and Ranging), Visual Intelligent Monitoring, Multi-sensor Data Fusion
√ Tau yooj yim tswj qis - qhov chaw teeb pom kev zoo thiab hmo ntuj scenes, thiab ua tau raws li qhov xav tau ntawm 24-teev soj ntsuam
√ 3D Reconstruction, pem hauv ntej-kawg tsom xam, txawj ntse qhia, pom lub teeb Linkage
√ Sau cov ntaub ntawv vis dis aus / duab, cia li saib xyuas thiab txheeb xyuas cov kev phom sij zais thiab muab cov lus ceeb toom ntxov rau lub sijhawm
√ Paub txog kev ua haujlwm ntawm kev saib xyuas online ntawm cov kab sib kis
Yog tias koj xav tau lidar pom kev txawj ntse saib xyuas los pab nrog koj txoj kev lag luam, thov kom dawb mus yuav nrog peb lub Hoobkas. Raws li ib qho ntawm cov ua lag luam nyob hauv Suav teb, peb yuav muab koj cov nqi qis thiab cov kev pabcuam tsis sib xws.
Peb cov kev daws teeb meem pom kev sib kis tau dav siv hauv State Grid thiab Tuam Tshoj Southern Power Grid. Peb tau teeb tsa peb lub hauv ntej - cov cuab yeej siv kawg ntawm 30,000 cov kab txuas txuas hauv Suav teb. Peb cov kev daws teeb meem yog siv los txhawm rau txheeb xyuas kev nyab xeeb kev nyab xeeb hauv cov kab hluav taws xob thiab kev sib txuas lus fibers, nrog rau hauv ib puag ncig ib puag ncig. Thiab nws yuav cia li ceeb toom rau lub platform online kom ceeb toom cov neeg ua haujlwm kom tswj tau. Qhov no ua rau txo qis qhov yuav tshwm sim ntawm kev raug xwm txheej (txo txo qhov hluav taws xob thiab kev mus ncig) thiab tuaj yeem hloov cov kev tshuaj xyuas phau ntawv. Nws daws 80% ntawm cov teeb meem kev soj ntsuam hluav taws xob ntawm 20% ntawm tus nqi. Kev saib xyuas dav dav thiab cov ntaub ntawv ceeb toom ntxov ntawm channel zais kev phom sij raug thawb hauv lub sijhawm 24 teev hauv ib hnub, uas txhim kho OHL kev tshuaj xyuas zoo.
| Video | |||||||||||||
| Kev piav qhia | |||||||||||||
Cov cuab yeej siv cov qauv tsim ntawm lub koob yees duab thiab LiDAR kev koom ua ke, thiab suav nrog tsis yog - rov ua dua LiDAR sensor. Los ntawm kev sib koom ua ke ntawm cov cuab yeej siv thev naus laus zis, ntau-sensor cov ntaub ntawv fusion thev naus laus zis, cov ntaub ntawv loj platform ntse tswj thev naus laus zis, tsim LiDAR tiag-lub sijhawm peb-dimensional reconfiguration ntawm lub zog xa hluav taws xob zais teeb meem muaj tseeb ntau yam khoom siv thiab pom kev ceeb toom, los daws qhov kis tau tus mob channel tsheb, kev loj hlob ntawm tsob ntoo, kev hloov pauv hauv av thiab cov teeb meem nyuaj arc. Pom tau qhov kis tau tus mob channel ntawm kev saib peb -seem reconstruction, kis tau tus mob zais teeb meem refinement thiab visualization ntawm kev ceeb toom thaum ntxov.
| Daim ntawv thov Background | |||||||||||||
Cov kab hluav taws xob siv hluav taws xob feem ntau yog ob peb mais mus rau ntau pua mais ntev. Cov khoom siv kab ua haujlwm nyob rau hauv ib puag ncig ntuj rau lub sijhawm ntev thiab cuam tshuam los ntawm ntau yam kev nyab xeeb (xws li cua daj cua dub, dej nyab, dej khov thiab daus, huab cua hnyav, muaj kuab paug, xob laim, thiab lwm yam); Tsis tas li ntawd, muaj lwm yam kev puas tsuaj sab nraud (xws li kev tsim kho tshuab kev puas tsuaj, thiab lwm yam). Cov xwm txheej no ua rau muaj kev phom sij rau kev nyab xeeb ntawm txoj kab txhua lub sijhawm. Yog li ntawd, ib zaug ib qho tsis ua hauj lwm tshwm sim, nws yuav siv sij hawm ntev los kho, ua rau muaj kev sib txawv ntawm kev poob. Nws yog ib qho tsim nyog los ntxiv dag zog rau kev tshuaj xyuas cov kab, kho thiab tshem tawm cov kev phom sij zais hauv lub sijhawm, thiab tsim cov kev ntsuas kev nyab xeeb.
| Vim li cas thiaj xaiv Senter Vision Intelligent Inspection Equipment for Overhead Transmission Lines | |||||||||||||
-
SENTER ST2303B siab-kev daws teeb meem kev ruaj ntseg lub koob yees duab saib qhov system tuaj yeem ua qhov chaw nyob deb saib xyuas. Nws tsim los siv rau hauv qhov chaw uas tsis muaj hluav taws xob hluav taws xob, tsis muaj lub network. Vim tias nws yog siv los ntawm lub hnub ci vaj huam sib luag, nws sib txuas lus nrog lub khoos phis tawj lossis lub xov tooj ntawm tes ntawm GSM, 2G, 3G, 4G.
-
Peb siv tsawg dua 20% ntawm tus nqi los daws 80% ntawm qhov xav tau cov ntsiab lus mob, txo tus nqi thiab txhim kho lub neej kev pabcuam.
-
Qhov tseem ceeb tshaj plaws yog tias peb tuaj yeem pom cov kev phom sij zais cia ua ntej, xws li hluav taws kub nyhiab, cranes, kev puas tsuaj rau cov noog thiab tag nrho cov kev phom sij uas yuav ua rau cov kab sib kis puas tsuaj, thiab tom qab ntawd cov neeg soj ntsuam tuaj yeem tuaj txog ntawm qhov chaw ua ntej, yog li txo cov hluav taws xob hluav taws xob zoo heev.
| Technical Parameter | |||||||||||||
|
Lub koob yees duab |
|
|
Sensor hom |
Hnub pom kev lens: 1/4-nti CMOS Hmo pom kev lens: 1/2 nti CMOS |
|
Pixels |
Hnub pom kev lens: 16 lab Hmo pom kev lens: 2 lab |
|
Kev daws teeb meem siab tshaj plaws |
Hnub pom kev lens: 4608 × 3456 Hmo ntuj pom kev lens: 1920 × 1080 |
|
Yam tsawg kawg illumination |
Xim: 0.001Lux@F1.5 Dub & Dawb: 0.0005Lux@F1.5 |
|
Lub koob yees duab lens |
|
|
Focal ntev ntawm lub lens |
Hnub pom kev lens: 3.7mm Hmo pom kev lens: 4.9mm |
|
Lens aperture |
Hnub pom kev lens: F2.0 Hmo pom kev lens: F1.65 |
|
Teb- ntawm- saib kaum |
Hnub pom kev lens: V50.6℃H64.3℃D76.2 degree Hmo pom kev lens: V46℃H82℃D94 degree |
|
Laser radar |
|
|
laser wavelength |
905nm ua |
|
FOV |
Tsis yog-Repeat Scan: 70.4℃(kab rov tav) x 77.2℃(Vertical) Rov ua dua Scanning: 70.4℃(kab rov tav) x 4.5℃(Vertical) |
|
Beam divergence kaum sab xis |
0.03℃(kab rov tav) x 0.28℃(ntu) |
|
Point huab tso zis |
240,000 ntsiab lus/sec (configurable thawj los yog muaj zog ncha) 480,000 ntsiab lus / sec (dual ncha) 720,000 ntsiab lus / sec (triple ncha) |
|
Cov ntaub ntawv ncua |
Tsawg dua los yog sib npaug li 2ms |
|
Tib neeg qhov muag kev nyab xeeb theem (HESL) |
Chav Kawm 1 (IEC 60825-1: 2014) Kev nyab xeeb ntawm tib neeg qhov muag |
|
Kev txawj ntse |
|
|
Kev txheeb xyuas qhov ntse |
Txhawb tsis siv neeg txheeb xyuas cov kev phom sij hauv kev sib kis: cov cuab yeej siv (ntauwd cranes, cranes, twj tsheb thauj khoom, excavators, bulldozers, shovels, rollers, forklifts, piling rigs, graders, gravers, insulated thoob tsheb thauj khoom, tsheb thauj khoom), cov khoom siv uas ploj lawm (insulators, cov khoom siv hluav taws xob uas ploj lawm nrog cov khoom siv hluav taws xob, cov khoom siv insulators. Cov pa taws los ntawm cov hluav taws kub (cov pa taws, qhib hluav taws), thiab cov khoom txawv teb chaws hauv cov xov hlau (cov khoom txawv teb chaws saum cov xov hlau, cov khoom txawv teb chaws nyob rau hauv cov xov hlau- plua plav- cov ntaub ntawv pov thawj, cov khoom txawv teb chaws hauv qab cov xov hlau - cov yeeb yaj kiab pom), thiab lwm yam. |
|
Pem hauv ntej-kawg tsom xam |
Txhawb kev tsom xam qhov phom sij zais cia ntawm sab ntaus ntawv tom qab lub cuab yeej tau ntes cov kev phom sij zais, thiab xa cov txiaj ntsig kev soj ntsuam ncaj qha rov qab mus rau tom qab- kawg, ua kom lub sijhawm nqus ntawm cov duab tsom xam thiab txo qhov siab ntawm sab nraub qaum- kawg server. |
|
Cov chaw khaws cia hauv zos rov qab - kawg nkag |
Cov cuab yeej txhawb nqa hauv zos khaws cia cov vis dis aus, coj lub voj voog los npog cov kev cia khoom, txhawb nqa rov qab -kawg txhua lub sijhawm kom nkag mus rau cov khoom siv sab hauv ntawm kev kaw video, txo cov nqi tsheb |
|
Kev tsom xam fusion |
Txhawb nqa tej thaj chaw deb ua rau LIDAR cov cuab yeej siv los sau cov ntaub ntawv huab cua hauv thaj chaw saib, thiab fusion tsom xam ntawm kev phom sij zais hauv thaj chaw saib siv cov duab thiab cov ntaub ntawv huab cua. |
|
Tig los ntawm kev sib txuas |
Kev txhawb nqa thiab pom kev sib txuas ntawm lub teeb pom kev, lub lens lens txhawm rau txheeb xyuas thiab txheeb xyuas qhov kev phom sij zais cia hauv thaj chaw saib tom qab kev sib txuas ntawm LiDAR los txheeb xyuas cov ntsiab lus huab huab hauv thaj chaw saib, thiab xa cov ntaub ntawv ceeb toom rau lub platform. |
|
Video |
|
|
Video compression txheem |
H.264; H.265; MJPEG |
|
Hnub-rau-Hmo hloov |
Lub Sijhawm Cheeb Tsam Positioning / Optical Sensing |
|
Dav dynamic (physics) |
Txhawb nqa |
|
Fog permeability |
Electronically pob tshab pos huab |
|
Teeb liab -rau- suab nrov piv |
Ntau dua lossis sib npaug li 55dB |
|
Anti-co muaj nuj nqi |
Electronic stabilization |
|
Internet |
|
|
Network raws tu qauv |
HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;Qos;FTP;UPnP;ICMP;SNMP;SNMPv1/v2c/v3(MIB2); IGMP;ARP;RTCP;RTIP;PPPoPE Lim; RTMP; Bonjour; TCP; SMB; NFS; NA |
|
Wireless standard |
3G / 4G / 5G Full Netcom (Mobile / Txuas / Telecom) |
|
Wi-Fi |
Txaus siab, tab sis pom zoo rau kev sim nkaus xwb |
|
Fais fab mov |
|
|
Txoj kev muab hluav taws xob |
Hnub ci vaj huam sib luag thiab roj teeb |
|
Kev siv fais fab |
0.25W (scanning point huab cov ntaub ntawv thiab thaij duab txhua 60 feeb) 0.35W (scanning point huab cov ntaub ntawv thiab thaij duab txhua 30 feeb) (Lub sijhawm ua haujlwm 30S, 24 teev hauv ib hnub) |
|
Hnub ci vaj huam sib luag / roj teeb muaj peev xwm |
Txheem 18V90W / 12.8V50AH 20-30 hnub 12.8V 120W / 12.8V 50AH Cov |
|
Fais fab mov |
Lithium Hlau Phosphate Roj teeb |
|
Ua haujlwm ib puag ncig |
|
|
Ua haujlwm kub |
-25℃~ +70 degree |
|
Kev khiav dej num |
Tsawg dua lossis sib npaug li 95% |
|
Chav kawm tiv thaiv |
IP67 |
|
Lub moj khaum |
|
|
Plhaub khoom |
Tuag-cast aluminium |
|
Khoom Loj |
370.9mm * 143.5mm * 134.7 hli (L × W × H) |
|
Net nyhav |
3.2kg ib |
|
Txoj kev teeb tsa |
Phab ntsa-mounted, kaum-mounted |
|
Lwm yam khoom |
|
|
Hmo pom kev qib |
Starlight Rating |
|
Cia muaj peev xwm |
Yeem ntxiv- ntawm daim npav TF 16G, 32G, 64G, 128G |
|
Kav hlau txais xov |
Ua -hauv kav hlau txais xov |
|
Positioning muaj nuj nqi |
Txhawb GPS |
|
MTBF |
Ntau tshaj lossis sib npaug rau 30000hours |
|
Lub koob yees duab adjustability |
Omni- kev taw qhia phau ntawv hloov kho raws li cov kab sib kis |
|
Saib xyuas lub voj voog |
Pem hauv ntej- xaus kev tshuaj ntsuam ntawm lub sijhawm ncua sij hawm ntawm 5 feeb ib daim duab, lub sijhawm rov qab los ntawm 1 teev ib daim duab, thiab lub sijhawm ua piv txwv tuaj yeem teem sijhawm dawb; cov cuab yeej siv duab rau pem hauv ntej- xaus kev tsom xam, txheeb xyuas cov teeb meem zais tam sim ntawd rov qab los, tsis muaj teeb meem zais rov qab raws sijhawm |
| Daim ntawv thov Scenario | |||||||||||||
Txhua qhov voltage theem kab channel thiab ntauwd saib xyuas.
OHL (hloov kab hluav taws xob)
Tiv thaiv kev puas tsuaj sab nraud rau saum - cov roj av thiab cov kav dej
| Daim ntawv thovteebmeem | |||||||||||||
Pom pom lub teeb duab
Point cloud modeling effect
Ntau-lub teeb fusion effect
Hidden Danger Ranging Effect
Qhov phom sij zais ntawmcov kab sib kis nws tus kheej
Kev kuaj dej khov
Tsis muaj insulator
Hlau sagging
Kev poob qis
| Kev teeb tsa | |||||||||||||
Ob tug neeg, peb kauj ruam, kaum feeb
lOb tug neegntawm kev ua haujlwm:Ib tug neeg nyob rau hauv av thiab ib tug neeg ntawm lub pej thuam tuaj yeem ua tiav qhov kev teeb tsa ntawm tag nrho cov khoom siv.
lPeb kauj ruam:Kev hloov kho yooj yim hauv qab tus pej thuam, Kev hloov me me los txhim kho ntawm tus pej thuam, kev sim kis mus rau hauv av
lKaum feeb:Lub installation ntawm lub cuab yeej tuaj yeem ua tiav hauv kaum feeb.
lTom qab installation:engineer yuav ua qee lub koob yees duab teeb tsa kom nws ua haujlwm nrog App thiab server.
| Txoj kev ua haujlwm | |||||||||||||
Nws tuaj yeem sau tau ntawm nws tus kheej lossis ua tus tswv tsev fusion terminal, thiab nws tuaj yeem txuas nrog lub davhlau ya nyob twg ntse.
| Qhia qhov tshwm sim | |||||||||||||
1. Field case
2.Channel foundations
